Expansion Memory Installation
A-4
DIMM to be used
Contact your Kyocera Mita dealer for information on purchasing the
DIMM that are best suited for use with this printer.
Either an 8 MB, 16 MB, 32 MB, 64 MB, 128 MB, or 256 MB DIMM can be
used for memory expansion.
Installing the DIMM
Insert the DIMM into the socket as follows:
1
Turn the printer’s power off, then unplug the printer’s power cable
and disconnect the printer from the host computer.
2
Remove the screw from the rear of the printer.
Figure A-6
3
Remove the side cover as shown in the figure.
Figure A-7
Side Cover
To Next Page
