Paper Jam Removal
3-16
3.4.2 Jam at the Paper Cassette
Pull out the paper cassette and remove any partially fed paper, then re-
close the paper cassette. Open and close the printer’s top cover to clear the
error. The printer then automatically warms up and resumes printing.
Follow the same steps for clearing the jammed paper at the option paper
feeder’s paper cassette.
Figure 3-2
3.4.3 Jam at the Duplexer
When a paper jam occurs in the duplex section, clear it using the following
procedure.
1
Open the rear cover and remove the jammed paper as shown in the
figure.
Figure 3-3
Paper Feeder’s Paper Cassette
Paper
Feeder
Paper Cassette
Rear Cover
To Next Page
