Using the Operation Panel
2-70 ADVANCED OPERATION GUIDE
6
Press [OK]. Processing appears, and the partition list is printed.
After the USB memory partition list is printed, the message display returns
to Ready.
Operating an Option Hard Disk
By installing the option hard disk into the printer, the e-MPS function can
be used. The printer’s menu selection system allows you to perform the
following operations on the hard disk.
If the option hard disk is not formatted, the >Format menu will
automatically appear on the message display.
• Reading Data
• Writing Data
• Deleting Data
• Printing of List of Partitions
The operations of the option hard disk are the same as those of the
memory card. Refer to the relevant sections in Using the CompactFlash
Card on page 2-62.
It also prints out the Directory Status List to confirm the directory or data
that is written in PJL or KPDL (PostScript).
Operating the RAM Disk
The RAM disk is a memory space shared within the printer memory that
can temporarily store print jobs. The RAM disk can be used only for
electronic sorting. The stored print job can then be used to print multiple
copies of the job reducing the total amount of time required to print the
whole job. It acts similarly to the hard disk except that the data is effective
only when the printer is powered up.
To set up the RAM disk, the option hard disk must not be installed.
To use the RAM disk, activate and enter the desired size of the RAM disk
in the manner described below. The maximum RAM disk size can be
calculated as follows:
Maximum RAM size = Total printer memory minus 36 MB
PARTITION LIST
FS-9530DN Page Printer
