Kyocera FS-C8500DN User Manual

Using the Operation Panel 4-25
Paper Output (Output location selection)
Select the output location. For details, refer to Paper Output (Selecting
the Paper Output Location) on page 4-58.
1 In the Copies menu or the Paper Selection menu, press
[Function] ([Right Select]). The Function menu appears.
2 Press U or V to select Paper Output.
3 Press [OK]. The Paper Output menu appears showing the
available output locations.
4 Press U or V to select the desired output location.
5 Press [OK]. The selected output location is stored and the Function
menu reappears.
Duplex (Setting the duplex printing)
Set duplex printing. For details, refer to Duplex (Setting the duplex
printing) on page 4-57.
1 In the Copies menu or the Paper Selection menu, press
[Function] ([Right Select]). The Function menu appears.
2 Press U or V to select Duplex.
3 Press [OK]. The Duplex screen appears showing the list of
available duplex printing modes.
4 Press U or V to select the desired duplex printing mode.
The message display toggles through the following:
Off (default)
Bind Long Edge
Bind Short Edge
Selecting Off disables duplex printing.
Note The screen varies depending on the installed options.
Function: a b
1 Paper Output
2 Duplex
3 Del. after Print
Paper Output: a b
1 *TopTray FaceDown
2 Tray A Face Down
3 Tray B Face UP
Note The screen shown appears when a 3,000 Sheet Document
Finisher is installed.
Function: a b
1 Paper Output
2 Duplex
3 Del. after Print
Duplex: a b
1 *Off
2 Bind Long Edge
3 Bind Short Edge

Kyocera FS-C8500DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	5.2 s
Time to first page (color, normal)	6.7 s
Print speed (black, normal quality, A3)	28 ppm
Print speed (color, normal quality, A3)	25 ppm
Print speed (black, normal quality, A4/US Letter)	55 ppm
Print speed (color, normal quality, A4/US Letter)	50 ppm
Internal memory	1024 MB
Processor model	PowerPC 750GL
Maximum internal memory	2048 MB
Sound power level (standby)	27, 26 dB
Sound pressure level (printing)	55 dB
Total input capacity	- sheets
Total output capacity	500 sheets
Maximum input capacity	100 sheets
Multi-Purpose tray input capacity	4100 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Standard interfaces	USB 2.0
USB 2.0 ports quantity	3
Network ready	No
Power requirements	220/240 V, 50/60 Hz
Wireless option type	Wireless LAN (802.11b/g)
Power consumption (active)	1250 W
Compatible operating systems	Windows, Mac OS X 10.2 +, UNIX, LINUX
Maximum duty cycle	150000 pages per month
Recommended duty cycle	25000 pages per month
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	200 W
Power consumption (PowerSave)	15 W
Display	LCD
Certification	GS, TÜV, CE

Weight and Dimensions

Dimensions (WxDxH)	605 x 680 x 691 mm
