Kyocera FS FS-1300D User Manual

Loading Paper 2-13
6 Insert the paper cassette into the slot in the printer. Push it straight in
as far as it will go.
There is a paper gauge on the left side of the front of the paper
cassette to indicate the remaining paper supply. When paper is
exhausted, the pointer will go down to the level of (empty).
7 Specify the paper size and type for the cassette using Configuration
Tool. For more information, refer to Configuration Tool on page 3-14.
Note Do not load paper above the triangle mark located on
the width guide.

Kyocera FS FS-1300D Specifications

General

Print Technology	Laser
Resolution	1200 x 1200 dpi
Connectivity	USB 2.0
Warm-up Time	15 seconds
Time to First Page	6 seconds
Output Capacity	250 sheets
Processor Frequency	360 MHz
First Print Out Time	6 seconds
Dimensions	375 x 393 x 250 mm
Weight	10.5 kg
Print Speed	28 ppm
Paper Capacity	250 sheets
Memory	32 MB
Supported Operating Systems	Windows, Mac, Linux
