Kyocera KM-5050 Service Manual

2GN/2GP/2GR-2
1-3-54
U241
Checking the operation of the switches of the finisher
Description
Displays the status of each switch of the 3000-sheet document finisher.
Purpose
To check the operation of each switch of the 3000-sheet document finisher.
Method
1. Press the start key.
2. Select the item to be checked.
Method: Checking the switch of the 3000-sheet document finisher
1. Turn the respective switches on and off manually to check the status.
When a switch is detected to be in the ON position, the display for that switch will be highlighted.
Maintenance
item No.
Description
Display Description
FINISHER Checking the switch of the 3000-sheet document finisher
MAIL BOX Checking the switch of the mailbox
BOOKLET Checking the switch of the centerfold unit
Display Switches
FRONT COVER SW Front cover switch (FCSW)
TOP COVER SW Top cover switch (TCSW)
RIGHT COVER SW Sub tray right switch (STRSW)
SET SW Joint switch (JSW)
BOOKLET SW Centerfold set switch (CSSW)
PUNCH TANK SW Punch waste box sensor (PWBS)
TRAY L-LIMIT SW Main tray lower limit detection sensor (MTLLDS)
TRAY U-LIMIT SW Main tray upper limit detection sensor (MTULDS)
TRAY MIDDLE SW Main tray middle position detection sensor (MTMPDS)
PAP HOLD DOWN SW Paper holder home position sensor (PHHPS)
LOAD DET SW Main tray load detection sensor (MTLDS)
FEED IN SW Paper entry sensor (PES)
EJECT SW 1 Eject switch 1 (ESW1)
EJECT SW 2 Eject switch 2 (ESW2)
EJECT SW 3 Eject switch 3 (ESW3)
STAPLE HP SW 1 Staple home position switch 1 (STHPSW1)
STAPLE HP SW 2 Staple home position switch 2 (STHPSW2)
MIDDLE FEED SW1 Internal tray paper entry sensor 1 (ITPES1)
MIDDLE FEED SW2 Internal tray paper entry sensor 2 (ITPES2)
BUNDLE DET SW 1 Paper detection sensor 1 (PDS1)
BUNDLE DET SW 2 Paper detection sensor 2 (PDS2)
BUNDLE UP HP SW Paper conveying belt home position sensor 1 (PCBHPS1)
BNDL DOWN HP SW Paper conveying belt home position sensor 2 (PCBHPS2)
WIDTH HP SW 1 Side registration home position sensor 1 (SRHPS1)
WIDTH HP SW 2 Side registration home position sensor 2 (SRHPS2)
BUNDLE INTERF SW Paper conveying belt position detection sensor (PCBDS)
VCARRY SW Centerfold paper conveying sensor (CPCS)

Kyocera KM-5050 Specifications

General

electrical requirements	120V, 60Hz, 11.5A
max monthly volume	200, 000 Pages Per Month
warm-up time	Within 30 Seconds
first copy out	3.5 Seconds
pages per minute	50 Letter, 26 Legal, 26 Ledger
system memory	Standard 512MB RAM, upgradeable to 1GB
hard disk drive	Standard 80GB HDD
resolution	600 x 600 DPI
standard paper sources	Dual 500 Sheet Drawers, 200 Sheet MPT
drawer paper size	5.5" x 8.5" - 11" x 17"
paper weight	13-28 lb Bond via Paper Drawers, 13 lb Bond -110 lb Index via MPT
paper size	5.5" x 8.5" – 11" x 17"
paper weight	17 – 20 lb Bond
capacity	100 Sheet DSDP / 50 Letter Size Originals Per Minute
dimensions	22.4”W x 20.7”D x 5.9”H
weight	29 lbs
stack capacity	Main Tray (A): 3, 000 Sheets; Sub Tray (B): 200 Sheets, Sub Tray (C): 50 Sheets
dimensions	26.9"W x 22.2"D x 42.8"H
weight	121 lbs
number of trays	7
dimensions	20.1"W x 15.7"D x 18.5"H
weight	22 lbs
weight	6.6 lbs
dimensions	25.9"W x 17.9”D x 10.5"H
weight	53 lbs
dimensions	22.0"W x 20.7"D x 36.0"H
weight	55 lbs
dimensions	12.2”W x 16.1”D x 6.3”H
weight	19.8 lbs
dimensions	23.0”W x 23.6”D x 12.4”H
weight	50.7 lbs
dimensions	23.0”W x 23.2”D x 12.4”H
weight	57.3 lbs

Weight and Dimensions

dimensions	23.6"W x 25.4"D x 29.3"H
weight	188 lbs
