1.TROUBLESHOOTING FOR THE HARDWARE
Clearing a Paper Jam 29
1 TROUBLESHOOTING FOR THE HARDWARE
14
Remove the paper.
15
Push up the two green levers.
16
Close the transport guide.
Close it by pressing the two knobs.
17
Return the Saddle Stitch unit to its original position.
18
Close the front cover first, and connect the Finisher
to the equipment.
Move it slowly placing your hands on the positions shown in the
figure.
Be careful not to let your fingers be caught between the
Finisher and the equipment.
