16
HOOK-UP—FIFTH WHEEL
1. Place tow vehicle close to pin box.
2. Raise or lower front end of RV as needed.
3. Back your tow vehicle against pin carefully.
4. Lower pin box until it touches hitch.
5. Release latch to lock pin to hitch. BE SURE it is locked to avoid a
drop on tow vehicle.
6. Raise front landing jacks and adjust feet so they clear any
objects.
7. Plug in your 7-way electrical cord from the tow vehicle to the
trailer connector.
FRONT LANDING JACKS
Front landing jacks on fifth wheel campers are available in two
different types. Mechanical gear driven jacks are operated with a
hand crank (manual) or optional 12 volt DC motor attached to gear
box. Power is supplied by “on board” battery or by tow vehicle while
attached with 7– way connector. A switch is mounted on front wall,
spring loaded to raise or lower jacks. Don’t forget to block the
wheels before you release the latch, raise pin box, and pull tow
vehicle away. An inline 30 amp fuse is located near the motor.
Now raise or lower front pin level your unit as needed.
TRAVELING_______________________________________
Weights
For safety reasons and federal regulations KZRV provides accurate
weight specifications to owners. On the exterior left front corner of
the coach you will find the Federal “Vehicle Identification Number”
sticker, as required by the federal government. This tag supplies
information concerning your coach, such as: VIN number, date/
month of manufacture, tire size rating, plus information about
weights as described on previous page and above.
Remember – always have the safety chain attached to tow vehicle, as
required in your state.
CAUTION
!
