69
Don’t forget loose items such as toasters, electric skillets, and coffee
pots also consume power. Include these also in your planning. 50
amp service provides another option.
50 Amp (Optional)
On some larger coaches, more appliances are desired by owners
which require more 120 volt AC power. Availability of 50 amp
service is the only method providing you with additional power.
For this application a larger circuit breaker box is required as there
are two separate banks of 120-volt AC power on the positive
position. Each positive bank receives a 120 volt wire marked “X” or
“Y” plus a white neutral wire and green/bare ground to complete
circuitry.
Do not replace breakers or fuses with any that are rated at a higher
amperage. Over fusing may cause a fire by overheating the wire.
DANGER
!
NEVER, under any circumstances, remove a grounding pin in any cord or
plug. It may mean the difference between LIFE OR DEATH.
WARNING
!
