37
Because operating the slide-out draws up to 15 amp current from the battery, some
source of supplemental charging should be operating while extending or retracting
the slide out
CAUTION
!
Inside of coach, on the wall, is a power injector with brown cover
where you hook-up to TV and/or satellite. There is an on/off
button on the power injector to engage the booster, located inside
of the antenna head.
Location of power injector is:
1. On the wall, above space for TV, free standing or wall
mounted.
2. Behind the TV.
3. Possibly on the ceiling close to TV location.
SLIDE-OUTS
With many models of trailers, KZRV uses numerous slide out
systems as listed below, followed by descriptions. Several different
vendors supply components, loose and/or attached to frames.
1. Below floor system. All metal components are external, located
under floor and inside of main frame rails and inside of
enclosed underbelly cover.
2. Above floor system. All components are inside and above floor,
to be found under dinette of sofa slide out.
3. Bed room and closet slide-out system. May be above floor or
below slide systems, same as above.
Before operating the power slide-out system in your coach, read
and become familiar with these instructions, along with components
and operation methods. Most of these components are inside of
the enclosed underbelly cover and can’t be seen.
POWER FOR OPERATION
Slide-out system is powered by 12 volt DC energy, produced by a
converter, transferring 120 volt AC into 12 volt. Automatic breakers
20 or 30 amp feed the motor when switch is engaged. Provision is
made to add an auxiliary 12 volt battery when 120 volt is not
