Authorized congurations with A15i-LIFT

Radial arrays of 1 to 6 enclosures

Refer to the illustrations to distribute the A15i-LIFT bars on the array.

1 enclosure :

1 A15i-LIFT

2 enclosures :

2 A15i-LIFT

3 enclosures :

1 A15i-LIFT

4 enclosures : 2 A15i-LIFT

5 enclosures : 2 A15i-LIFT 6 enclosures : 2 A15i-LIFT

Radial arrays of 7 enclosures and more

Refer to the illustrations to distribute the A15i-LIFT bars on the array.

In radial arrays of 7 enclosures and more, make sure the site angle is 0°.

Position the pickup points so that the center of gravity is in the middle of the array.

7 enclosures : 3 A15i-LIFT 8 enclosures : 4 A15i-LIFT 9 enclosures : 3 A15i-LIFT

Array setup information

type number of enclosures number of motors pickup point

for 0° site angle

7 3 —

8 2 (2 bridles) 8A15i Focus

9 3 —

7 3 —

8 2 (2 bridles) 13A15i Wide

9 3 —

112 A15i owner's manual (EN) version 1.0
