Rigging procedures
Flying a radial array with A15i-LIFT
Type of deployment own radial array
Rigging accessories A15i Wide/Focus rigging plates
one A15i-LIFT for three enclosures
LA-SLING2T or a bridle (optional)
Ø12 mm shackles WLL 1 t (provided)
Additional accessories M6x18 rigging screws (provided)
T30 Torx bit
Min number of operators 2
Rigging plates
x2 x2
x2 x2
x2 x2
x2 x2
A15iFOCUS-LINK
Rigging plates
for A15i Focus
A15iFOCUS-ENDLINK
End rigging plates
for A15i Focus
A15iWIDE-LINK
Rigging plates
for A15i Wide
A15iWIDE-ENDLINK
End rigging plates
for A15i Wide
Risk of falling objects
Verify that no unattached items remain on the product or assembly.
Additional safety with A15i-LIFT
On each enclosure on which A15i-LIFT is secured, secure a DIN580 eye bolt to the dedicated insert to implement
a secondary safety.
Use a shackle and a steel wire rope. Make sure the steel rope is as tensed as possible without bearing the load.
A15i owner's manual (EN) version 1.0 69
