Authorized congurations with A15i-LIFT
Authorized congurations with A15i-LIFT
Safety instructions
Additional safety with A15i-LIFT
On each enclosure on which A15i-LIFT is secured, secure a DIN580 eye bolt to the dedicated insert to implement
a secondary safety.
Use a shackle and a steel wire rope. Make sure the steel rope is as tensed as possible without bearing the load.
A15i-LIFT quantity and position
Use one A15i-LIFT for up to three enclosures in the array.
Do not leave more than two adjacent enclosures unsupported.
Refer to APPENDIX A: Authorized congurations with A15i-LIFT (p.111).
A15i-LIFT pickup point
Select the same pickup point on each A15i-LIFT within an array of up to 6 enclosures.
For larger arrays, refer to Radial arrays of 7 enclosures and more (p.112).
Risk of tilting
When using a single motor or a bridle, make sure the array is symmetrical.
When using a third-party bridle, make sure the angle between the two chains does not exceed 60°.
Hybrid congurations
Either A15i Wide, A15i Focus or a combination of both can be used as illustrated.
A15i owner's manual (EN) version 1.0 111
