Rigging procedures
Adding a pullback with A15i-RIGBAR
Type of deployment own array with pullback
Rigging accessories A15i-RIGBAR
1 x Ø12 mm shackle WLL 1 t (provided)
Additional accessories M6x40 screws (provided)
M6x18 rigging screws (provided)
T30 Torx bit
Min number of operators 1
Risk of falling objects
Verify that no unattached items remain on the product or assembly.
Secondary safety
Use available holes on the rigging accessories to implement a secondary safety.
Assembly
Procedure
1. Prepare a vertical array as described in Flying a vertical array with A15i-BUMP (p.53) or Flying a vertical array with
A15i-RIGBAR (p.65).
2. Raise the array until the bottom enclosure is accessible.
3. Remove the screw from the bottom rear hole of the bottom enclosure on each side.
4. Secure A15i-RIGBAR at the bottom rear of the bottom enclosure.
A15i owner's manual (EN) version 1.0 67
