L-Acoustics A15i Series User Manual

System components
System components
Loudspeaker enclosures
A15i Focus 2-way passive constant curvature WST
®
10° enclosure: 15" LF + 3" HF diaphragm (installation
version)
A15i Wide 2-way passive constant curvature WST
®
30° enclosure: 15" LF + 3" HF diaphragm (installation
version)
KS21i High power compact subwoofer: 1 x 21" (installation version)
Powering and driving system
LA2Xi / LA4X / LA8 /
LA12X
Amplied controller with DSP, preset library and networking capabilities
Refer to the LA2Xi / LA4X / LA8 / LA12X owner's manual for operating instructions.
Loudspeaker cables
speaker cable 2.5mm
2
cable
Speaker cable used to connect enclosures in parallel. Adapt the cable length to the installation.
custom 2-point
speakON cable
2-point speakON cable (2.5mm
2
gauge) to bare wire cable
This cable needs to be custom made.
Information about the connection of the enclosures to the LA amplied controllers is given in
this document.
Refer to the LA2Xi / LA4X / LA8 / LA12X owner's manual for detailed instructions about the whole cabling
scheme, including modulation cables and network.
Rigging elements
A15i-BUMP Flying frame for vertical deployment of A15i and KS21i
A15i-LIFT Rigging element for horizontal deployment of A15i
A15i-RIGBAR Rigging bar and pullback for A15i and KS21i
A-U15i U-bracket for A15i and KS21i
Ai-FIXBRACKET Fastening bracket for A15i, A10i and KS21i
A15i-TILTBRACKET Fastening bracket with angles for A15i
M-BARi Extension bar for rigging frame (installation version)
A15i-TILT Rigging element with angles for A15i above or under KS21i
KS21i-LINK Rigging plates for KS21i
KS21i-ENDLINK End rigging plates for KS21i
KS21i-SLINK Rear rigging plates for A15i and A10i onto or under KS21i
KS21i-ENDSLINK End rear rigging plates for A15i and A10i onto or under KS21i
A15iFOCUS-LINK Rigging plates for A15i Focus
A15iWIDE-LINK Rigging plates for A15i Wide
A15iWIDE-ENDLINK End rigging plates for A15i Wide
A15iFOCUS-ENDLINK End rigging plates for A15i Focus
A15i-ULINK Rigging plates for ying two A15i with A-U15i
