L-Acoustics A15i Series User Manual

Congurations with A-U15i
Congurations with A-U15i
A15i Wide/Focus
Inserts for U-bracket
A
B
C
conguration number of
enclosures
reference
axis
coverage resolution holes used on enclosure
1 0° (site) -30° / +30° 5°
B+C (for -30°
to +30° in
10° steps)
A+B (for -25°
to +25° in
10° steps)
2 0° (site) -30° / +30° 10° B+C
1 0° (site) -25° / +25° 10° B+C
1 -90° (site) -30° / +30° 10° B+C
1 0° (site) -30° / +30° 10° B+C
2 0° (site)
Refer to
coverage
table
(p.115)
10° B+C
A15i owner's manual (EN) version 1.0 113
