Rigging procedures
Securing a screen
Accessory A15iFOCUS-SCREEN / A15iWIDE-SCREEN / A15iFOCUS-SCREEN-LIFT /
A15iWIDE-SCREEN-LIFT / KS21i-SCREEN
Additional accessories 2 x M6x20 screws (provided)
2 x M6x35 screws (for A15i Wide/Focus, provided)
2 x M6x55 screws (for KS21i, provided)
4 x self-sticking washers (for congurations with a U-bracket, provided)
T30 Torx bit
Min number of operators 1
Assembly
Prerequisite
Secure the screens on the enclosures after the array is fully assembled.
About this task
In radial congurations, use A15iFOCUS-SCREEN-LIFT/A15iWIDE-SCREEN-LIFT for enclosures on which A15i-LIFT
is secured.
94 A15i owner's manual (EN) version 1.0
