Rigging system description
Enclosures
A15i Wide/Focus
A15i Wide/Focus is compatible with two types of rigging plate kits:
• standard rigging plates
(A15iFOCUS-LINK / A15iWIDE-LINK)
• end rigging plates
(A15iFOCUS-ENDLINK / A15iWIDE-ENDLINK)
A15iFOCUS-LINK can be used to add an inter-element angle of 5° between two A15i Focus.
A15i Wide/Focus feature on each side:
• Four M6 inserts for own
congurations with a rigging
frame or stacked congurations.
• Three M8 inserts for wall-
mounting or ceiling-mounting with
a bracket.
• Two M6 inserts for securing a
screen.
The inserts are tted with placeholder screws.
A15i owner's manual (EN) version 1.0 23
