L-Acoustics A15i Series User Manual

Rigging system description
Secure A15i-TILTBRACKET at the bottom of an array of up to two A15i Wide/Focus to adjust the site angle.
The angle can be set between 0° and -25° in 2.5° steps.
0°
-2.5°
-5°
-7.5°
-10°
-12.5°
-15°
-17.5°
-20°
-22.5°
-25°
Ai-FIXBRACKET and A15i-TILTBRACKET can also be used to mount up to two A15i Wide/Focus or KS21i under the
ceiling.
Ai-FIXBRACKET and A15i-TILTBRACKET must be secured to the supporting xture with four M10 screws.
Fasteners for wall-mounting or ceiling-mounting
Select screw length and anchors applicable to the wall or ceiling properties.
A15i owner's manual (EN) version 1.0 37
