L-Acoustics A15i Series User Manual

Rigging procedures
6. Prepare a new enclosure by removing the placeholder screws and securing rigging plates.
7. Remove the bottom screws of the supporting enclosure.
8. Link the two enclosures at the rear by pre-tightening a rigging screw on both sides.
This step requires three operators.
Hold the enclosure at the bottom until the rigging plates are secured.
A15i Focus site angle adjustment
A15iFOCUS-LINK can be used to add an inter-element angle of 5° between two A15i Focus.
A15i owner's manual (EN) version 1.0 83
