Rigging procedures
6. Position another K3 on the rst one.
Keep holding the enclosure with the handles until the front rigging arm is secured.
7. While holding the handle, rotate the front rigging arm and secure it with both LINK pins.
K3 owner's manual (EN) version 1.0 63
