2. Denition of Available Models
This operating manual refers exclusively to the following models, of our own manufacture:
LEVA S, model 3 groups
1 Pressure Gauge (coffee boiler)
2 Main Switch
3 Steam Wand Lever
4 Delivery Lever
5 Hot Water Wand
6 Hot Water Mix Valve
7 Tea Water Button
8 Programming Display
9 Pressure Gauge (steam boiler)
10 Steam Wand
11 Removable Drain Tray
12 Waste Water Hose Holder
13 Drain Tray Grate
14 USB Key Connection
15 Delivery Group
Legend
Fig. 1a - Model LEVA S - 2 or 3 groups
For additional information on electronics,
keypads, and software programming,
please see the section entitled Software
Programming your Espresso Machine.
