8 TECHNICAL SPECIFICATIONS
Following are the technical specifications for the PLM Series PLM 10000Q. These figures are accurate at the
time of printing but please note that all figures are subject to change without notice. For the most accurate
and current information available, please visit www.labgruppen.com/plm.
Item no. TDS-PLM10000Q_V8
Lab.gruppen ab • Sweden
internationaL contact • info@Labgruppen.com | uS contact • info@tcuS.com
www.labgruppen.com
General
Number of input channels 2
Number of output channels 4
Peak total output all channels driven 10800 W
Max. Peak output voltage per channel 153 V
Max. output current per channel 35.5 Arms
Max. Output Power 2 ohms 2.7 ohms 4 ohms 8 ohms 16 ohms
All channels driven 2350 W 2700 W 2300 W 1300 W 660 W
Channels A and B, while channels C and D are driven at -3 dB
2)
2350 W 2900 W 2400 W 1300 W 660 W
Audio Performance
THD + N 20 Hz - 20 kHz for 1 W <0.05%
THD + N at 1 kHz and 1 dB below clipping <0.04%
Dynamic range with digital inputs (for all supported sample rates) >116 dBA
Dynamic range with analog inputs >114 dB
Frequency response (1 W into 8 ohms, 20 Hz - 20 kHz) + /- 0.05 dB
Input Common Mode Rejection (CMR) 20 Hz to 1 khz > 78 dB
Internal sample rate 96 k
Internal data path 32 bit fl oating point
Product propagation delay, best case (96 kHz AES) 1.90 ms
Product propagation delay, analog input 1.85 ms
Sample Rate Converters
THD + Noise 0.00003 %, 20 Hz - 20 kHz, unweighted
Analog to Digital inputs
THD + Noise 0.00022 %, typical at 1 kHz unweighted at +21 dBu headroom setting
0.00033 %, typical at 20 Hz and 20 kHz unweighted at +21 dBu headroom setting
AES / EBU inputs
Supported resolutions ≤ 24 bit
Supported sample rates 44.1, 48, 88.2, 96, 176.4, 192 kHz
Dante Audio Network
Supports redundant paths Yes
Flexible topology Yes
Network latency <500 µs
Device presets
Local memory locations for the settings of the product 100
Limiters
Adjustable Inter-Sample Voltage Peak Limiter (ISVPL) 17.8 - 153 V, step size 0.1 V
Current Limiter 35.5 Arms
LimiterMax (rms and peak limiters)
– MaxRMS (rms voltage limiter) Yes
– MaxPeak (peak voltage limiter) Yes
Current Average Limiter (CAL) (max average during 500 ms) 25 Arms
Gain
Amplifi er gain 22 - 44 dB, step size 0.1 dB
Analog attenuator -Inf to 0 dB, step size 0.25 dB
Back panel interface
AES / EBU / I/O (input + link) 2 x 3-pin XLR
Analog, 2-channel I/O (input + link) 4 x 3-pin XLR, electronically balanced
Output connectors Neutrik Speakon (1 x NLT8, 2 x NLT4) or 4 Binding Posts (pairs) (must be specifi ed upon order)
Auto 10/100, Auto Uplink 2 x RJ45 EtherCon
Control and monitoring interface Via Ethernet for Dolby Lake Controller software
Detachable mains cord Neutrik PowerCon 32 A
Cooling Two fans, front-to-rear airflow, temperature controlled speed
Front-panel user interface:
Display, daylight readable LCD 2.5 inch
Fault/ Warning/Limit/Clip indicators RGB LEDs
Mute and soft function buttons 8 provided
Standby Power button On/Off
Mute Enable button Enables muting of outputs and inputs via soft-button keypad
Meter button Toggles through meter views
Menu button Provides a menu driven interface for full function front panel control
Rotary Encoder Yes
Exit button Provides a “back” function
Power
Operating voltage, 230 V / 115 V nominal
1)
140-265 V / 70-135 V (45 - 66 Hz)
Soft start / Inrush Current Draw Yes / max. 5 A
Mains Power Average Limiter (PAL) Yes
Dimensions (W/H/D) W: 483 mm (19”), H: 88 mm (2 U), Overall D: 470 mm (18.5”) deep including handles and rear support.
Weight 13 kg (29 lbs.)
Finish Black painted steel chassis with black painted steel / aluminum front
Approvals CE, ANSI/UL 60065 (ETL), CSA C22.2 NO. 60065, FCC
Note 1): Separate 230 V or 115 V versions available. Not selectable on the product.
Note 2): Assymetrically loading the output channels (as shown, for example): If some channels have reduced output power requirements, the voltage drop from the power supply will be reduced,
resulting in a higher voltage and power output for the other channels.
All specifications are subject to change without notice.
Intercooler and Class TD are national and/or international registered trademarks of Lab.gruppen AB. PLM, Powered Loudspeaker Management, R.SMPS, LoadLibrary, LoadSmart,
SpeakerSafe and ISVPL are trademarks of Lab.gruppen AB. Dolby, Lake, and the double-D symbol are registered trademarks of Dolby Laboratories. Dolby Lake Processor, Lake
Contour, Lake Mesa Quad EQ, LimiterMax and Iso-Float are trademarks of Dolby Laboratories. All other trademarks remain the property of their respective owners.
Copyright © 2008 Lab.gruppen AB. All rights reserved.
Specifications PLM 10000Q

Lab.gruppen PLM Series PLM 10000Q Specifications

General

Output Power (per channel at 2 ohms)	2500 W
Output Power (per channel at 4 ohms)	2300 W
Output Power (per channel at 8 ohms)	1250 W
Output Power (per channel at 16 ohms)	625 W
Total Output Power	10000 W
Number of channels	4
Sample Rate	96 kHz
Latency	1.5 ms
THD+N	<0.1%
Damping Factor	> 500
Dimensions	88 x 483 x 396 mm
Cooling	front-to-rear airflow
Protection	DC, thermal, short circuit
Connectors	SpeakON
Voltage	100-240 V AC
Signal to Noise Ratio	>112 dBA
Input Impedance	20k ohms (balanced), 10k ohms (unbalanced)
