Label NEXT 120s - Page 35

35
F44 Not used
F45m Not used
F48 Not used
F49
OFF*
It enables the buzzer warning beep when the motor thrust power limit is reached (refer to the paragraph
"Functional testing").
S
ON It disables the buzzer warning beep when the motor thrust power limit is reached.
F50 Not used
F51 Not used
F52 Not used
F53 Not used
F54 Not used
F55 Not used
F56 Not used
F57 Not used
F58 Not used
F59 Not used
F60 Not used
F61 Not used
F62 Not used
F63 Not used
F64 Not used
F65 Not used
F66 Not used
F67 Not used
F68 Not used
F69 Not used
F70 Not used
F71 Not used
F72 Not used
F73
OFF* Opening leaf braking stage start in advance with relation to the end of the manoeuvre.. S
ON Opening leaf braking stage start corresponding to the last degrees of the manoeuvre.
F74 Not used
F75 Not used
F76 Not used
F77
OFF* Privacy Function not active
ON Privacy Function active (Please check paragraph “PRIVACY FUNCTION”)
F78
Function
active if
F77 = ON
OFF*
for maglock without status sensor open/closed (factory setting) The operator NEXT 120S is automatically
detecting the close door status.
ON
Read this function just in case you install a maglock with status sensor open/closed (not supplied by Label)
for maglock with status sensor open/close. Connect the N.O output contact of the status sensor to the
input AUX1 on NEXT‑L120S control unit in order to detect the close door status.
F79
Function
active if
F77 = ON
OFF
The tra󰀩c light (D) show steady green light during the door movement and until the locking impulse is
given by the user.
ON*
The tra󰀩c light (D) slowly ashes red/green light during the door movement and then rapidly at door
closed until the locking impulse is given by the user.
As soon as the door is closed, the tra󰀩c light will show red light.
F80
OFF* Cyclic function OFF
ON
Cyclic function ON.
It activates the continuous door opening and closing cycle; it is only used for operation or durability tests.
