38
P33 Motor thrust distance at closing end (active only with F38 = OFF)
At the default value 0%, the function is disabled.
Increasing the value increases the degrees from the end of the closing run in which the motor
thrust is enabled to facilitate the completion of the closing manoeuvre, in critical situations caused,
for example, by draughts.
At 100% of the value the motor is enabled throughout the closing phase.
The thrust power of the motor is regulated by the potentiometer P15.
S
P34
Parameter active if
F77 = ON
Adjustment of the time within which the user can activate door locking from inside once the door is
closed. At value "0" the time is set to innite; therefore, it is always possible to activate door locking
through the internal touchless sensor. From value "1" to "100", the time is adjusted between 1 and
100 seconds (factory setting = 10 seconds).
Once this time period has expired, the maglock is not engaged and the touchless sensor will
activate door opening.
P35
Parameter active if
F77 = ON
Adjustment of the time after which the maglock is released automatically if the door has been
locked from inside. At value "0" (factory setting) the time is set to innite; therefore, the maglock
keeps the door locked until the user activates the internal touchless sensor to open the door and
exit. From value "1" to "100", time is set from 1 to 100 minutes.
Once this time period is expired the trac light ashes red/green, advising the user that door will
be unlocked within 3 minutes.
P36 Not used
P37 Not used
P38 Not used
P39 Not used
P40 Not used
P41 Not used
P42 Not used
P43 Slowdown ramp during opening
Increasing the value, leaf slowdown moves toward the last degrees of the opening cycle.
S
P44 Intensity of the braking during opening
Increasing the value increases door braking intensity during the opening cycle.
S
P45 Not used
P46 Not used
P47 Not used
P48 Scheduled maintenance
This parameter allows to select the number of opening/closing cycles after which the message
"SCHEDULED MAINTENANCE" appears on the display of the program selector.
The maintenance signal can also be displayed on the open collector output between the terminals
S-24 of the electronic control unit if the operating mode C is selected in the function F41m.
When set to OFF (default value), the scheduled maintenance message is never displayed.
Select the number of cycles after which maintenance is to be reported according to door operation
and to the usage conditions:
8K (8,000 cycles), 16K (16,000 cycles), 32K (32,000 cycles), 64K (64,000 cycles), 128K (128,000
cycles), 256K (256,000 cycles), 512K (512,000 cycles).
P49 Not used
P50 Not used
