108
Table 8a
Main parameters and characteristics of the vehicle 2191 «liftback»
Engine model 11186 21126 21126
Powertrain type mechanical gearbox mechanical gearbox automatic gearbox
Number of doors 5
Number of seats, pers. 5 (first row – 2, second row – 3)
Number of seats with fully folded rear seats, pers. 2
Overall dimensions, mm Fig. 67
Layout scheme with transverse engine mounting and front-wheel drive
Engine type four-stroke, spark-plug ignition
Engine fuel feeding system electronically controlled fuel injection
Engine ignition system electronic ignition with static distribution
Engine displacement, сm
3
1596
Number of cylinders 4
Engine cylinder arrangement in-line
Number of valves in the engine cylinders 8 16
Nominal compression ratio in the engine cylinders 10,3 11,0
Maximum engine power, kW (min
-1
), 64,0 (5100) 72,0 (5600)
according to (ISO 1585)
Maximum engine torque, N•m (min
-1
) 140,0 (3800) 145,0 (4000)
Fuel Premium Euro-95
Kerb weight (with driver 75 kg), kg:
– min weight, kg 1080
– max weight, kg 1140
Variant of design
Norm
