8* 115
Tab l e 2
ENGINE OIL
Based on the table below, determine the level of quality
and oil viscosity grade, prescribed for your vehicle in accor-
dance with the existing operating temperature range.
If necessary – change the oil. For this purpose refer to the
authorized service center.
Use only recommended operating and lubricating fluids. For information on the recommended operating and lubricating fluids,
refer to the authorized service center.
Filling point
Engine lubrication
system
Description
Minimum temperature of cooling medium under
the vehicle operation
0
С
SAE J 300 viscosity
grade
Maximum environment temperature under the
vehicle operation,
0
С
Engine oil
SAE viscosity grades and operating temperature range
The quality level of operational properties: API SL/АPI SM/API SN
СТО ААИ 003 Б5/СТО ААИ 003 Б6
-40 0W-30 25
-40 0W-40 30
–30 5W-30 25
–30 5W-40 35
–25 10W-30 25
–25 10W-40 35
–20 15W-40 45
–15 20W-40 45
–15 20W-50 up 45
