Lada GRANTA User Manual

Installation of ISOFIX child
restraints
Your car is equipped with the
ISOFIX system holders allocated on
the rear seats, which allow to install
the child restraints with ISOFIX hold-
ers complying with the requirements
of ЕСЕ-R44 standard (for children
with weight up to 18 kg).
The ISOFIX system consists of two
lower ISOFIX holders and upper
ISOFIX safety belt holder.
The lower ISOFIX holders with
jointed appropriate child ISOFIX
restraint holders are allocated in the
lower part of the rear seat back.
Their allocation is marked by
round signs .
Before ISOFIX child restraints
holders joining it is necessary to
clear zone of lower ISOFIX holders
by placing the rear safety belts locks
in the junction line of rear seat cush-
ion and back.
Bracket for upper ISOFIX safety
belt signed and is allocat-
ed on the rear shelf behind the rele-
vant seat (for model 2190) or in the
lower part of the rear seat back on
the luggage compartment side (for
model 2191).
26
The ISOFIX child restrainers Diagram
Weight group
«0»
(up to 10 kg –
about 0-6
months)
«0»
(up to 13 kg –
about 6-18
months)
«I»
(9-18 kg –
about 9
months – 3,5
years)
ISOFIX mounting positions in the vehicle
XXX
XXX
IL** X IL**
IL** X IL**
XXX
XXX
XXX
XXX
IUF IUF IUF
IUF IUF IUF
IUF IUF IUF
ISOFIX dimensional class
rear seat right
hand place
central rear
seat place*
(for model 2190)
rear seat left
hand place
F (Baby bassinet)
G (Baby bassinet)
Е (Rearward-facing seat)
E (Rearward-facing seat)
D (Rearward-facing seat)
C (Rearward-facing seat)
D (Rearward-facing seat)
C (Rearward-facing seat)
B (Facing front seat)
B1 (Facing front seat)
A (Facing front seat)
Table 1a
IUF – a seating space suitable for installation of the ISOFIX «universal» child restrainer for this dimensional class.
IL – a seating space suitable for installation of the ISOFIX «semi-universal» child restrainer for this dimensional
class.
X – a seating space not suitable for installation of the ISOFIX child restrainer.
* When installing the ISOFIX child restrainer to the central space of rear solid seat the installation of ISOFIX child
restrainers to the side seating spaces is excluded.
** At the date of publication the recommended child seat of this ISOFIX dimensional class is Britax Romer Baby
Safe seat.
