К1 50А Load reduction relay of the ignition switch
К2 30А Starter relay
К3 40А Radiator electric cooling fans relay
К4 30А Radiator electric cooling fans relay
К5 30А Air conditioner compressor clutch relay
К6 30А Rear window and outside mirrors defroster relay
К7 20А High beam relay
К8 20А Audio signal (horn) relay
К9 20А Low beam relay
К10 20А Backup light relay
К11 20А Electronic engine management system main relay
К12 20А Fuel pump relay
К13 20А Seats heating relay
К14 70А Windshield heating relay
К15 Reserve
К16 Reserve
К17 Reserve
К18 Reserve
Table 6
Relay located within fuse block and passenger compartment relay in «Luxe» version*
Switched circuit
Relay No
Relay
output capacity
* It is specified the set of relays for the top level of equipment – «Luxe» (depending on the set of options selected some fuses of this set in other versions
may not be used)
