Lamtec F 200 K User Manual

- 10 -
- admissible switching current 0.5 A maximally
10 mA minimally, at a limit
load of 50 mA
- Switching capacity 0.1 W minimally
30 W maximally
- Internal fuses, 500 mA slow IEC and/or
750 mA slow UL
- Safety period "Operation" t
VOff
≤ 1 s and/or ≤ 3 s,
factory set
- Start-up delay t
VOn
≈ 1 s and/or ≈ 3 s
Measuring output for intensity
- Output continuous current 4 (0 )... 20 mA, there is no insulation
of potential towards the supply
voltage
- Maximum working resistance 220 Ω
- Floating DC voltage 6.6 V
- Basic error ± 2 %
Dynamic characteristics
Self-monitoring cycle t
CYCLE
ca. 3.0 s for safety period
t
VOff
≤ 1 s
t
CYCLE
ca. 7.0 s for safety period
t
VOff
≤ 3 s
Cable length LiYCY 8x1x0.5
Coupling part with standard cable length 3 m
(is also available in variable length if the customers requires so)
Extension of more than 3 m with LiYCY 8x1x0.5 to 50 m
Extension of more than 3 m with LiYCY 8x1x1.0 to 100 m
Extension of more than 3 m with LiYCY 8x1x2.5 to 250 m
Taking into account the electrical basic conditions, it also possible to bridge major dis-
tances using smaller cable core sections. An important criterion is the compliance with
the supply voltage limits at the compact flame detector, and thus the voltage drop in
supply voltage coming through the supply line.
Technical stressability
Operating mode DB
Creepage distances and clearances DIN EN 60730 part 1
Interference susceptibility DIN EN 60730-1, EN 61000-4
Emitted interference DIN EN 55011/A1
Radio interference suppression
The output contacts of the flame detector have no radio interference suppression. The
user is required to take the appropriate radio interference suppression measures on
the basis of the overall installation design. In order to ensure the required safety, carry
out the installation circuitry in such a way as to avoid shorting-out of the contacts by
defective components of the interference suppression unit.
Climatic stressability
Installation category Temp. min. - 20 °C
max. +60 °C
rel. air humidity 80 % at 35 °C
