Lamtec F 200 K User Manual

- 30 -
12 Examples of application
12.1 Interconnection with Etamatic
0 V
4(0)..20 mA
without function
24 V
F 200 K1
FPE
Connection cable
RT
BU
Sch
GY
PK
YE
GN
BN
WH
N
L
PE
24V
DC
Etamatic
PE
PE
22
23
53
24
+24V
+24V
Flame signal
12.2 Interconnection with FMS
0 V
4(0)..20 mA
Range
24 V
F 200 K2
FPE
Connection cable
RT
BU
Sch
GY
PK
YE
GN
BN
WH
N
L
PE
24V
DC
FMS
PE
PE
31
10
8
9
+24V
+24V
Flame signal
*
*
Use depends on application
56 Flame intensity
WH - white - weiß PK - pink - rosa BU - blue - blau
BN - brown - braun YE - yellow - gelb GY - grey - grau
GN - green - grün RT - red - rot Sch - shield - Schirm
