- 32 -
- Admissible switching current max. 0.5 A
min. 10 mA, at a limit load
of 50 mA
- Switching capacity min. 0.1 W
on DC voltage max. 30 W
on AC voltage max. 120 W
- External fuse ≤ 500 mA slow IEC, ≤ 750 mA slow UL
Caution !
Output contact, safe << >> signalling contact
Electrical insulation is effected through base insulation, i.e. it is not allowed to simulta-
neously apply SELV (protective low voltage) and mains voltage to the two contacts.
However, low voltage and SELV and/or low voltage and mains voltage can be applied
at the same time.
Connection core section
- flexible 0.5 .. 2.5 mm²
- rapid 0.5 .. 4.0 mm²
Technical stressability
Operating mode Continuous operation
Creepage distances and clearances DIN EN 60730 part 1
Radio Interference Suppression
The output contacts of the flame detector have no radio interference suppression.
The user is required to take the appropriate radio interference suppression meas-
ures on the basis of the overall installation design.
In order to ensure the required safety, carry out the installation circuitry in such a way
as to avoid shorting-out of the contacts by defective components of the interference
suppression unit.
Climatic stressability
Installation category Temp. min. - 20 °C
max. +60 °C
rel. air humidity 80 % at 35 °C
Protection type IP 20; without further enclosure
IP 65; built-in in IP 65 enclosure, which is
available for delivery
Weight 0.35 kg
Storage conditions (in original packing)
Storage location closed premises
Air temperature - 40 ... +70 °C
Air humidity max. 80% at 35 °C
Transport conditions (in original packing)
Type of transport in closed holds
Air temperature - 40 ... + 70 °C
Temperature- humidity- coupling max. 80% at 35 °C
