Product Description
3.3
Rating Plate
Y
ou will find details of the configuration on the rating plate:
T
ype plate example:
NOTICE
The flame monitoring device is only available in the 120V version with UL approval..
Fig. 3-1 T
ype plate FFS07 and 08
10
