Appendix
1
1.1.3
Connection Housing
1
1.1.3.1
FG 21 Connecting housing (Aluminium)
Fig. 1
1-9 Dimensions FG 21 Connecting
housing (Aluminium)
T
echnical Data
Protection class:
IP65
Ambient temperature range:
- 30 … + 90 °C
Relative humidity:
50% at 40°C100% at 25 °C (short term)
Weight:
0,43 kg
54
56
