18
3 Product Description
3.5.2 Connection Housing
You may use the connection housing offered by LAMTEC or customary connection housing.
Beside all usual requirements respect the additional requirements in chapter 5.1 Safety for
mounting and installation.
3.5.3 Flame Scanner Testing Device
Fig. 3-9 FFP30 flame-scanner testing device
You can use the FFP30 to test that your flame scanner is working properly.
The testing device simulates a variable flame frequency
The testing device is screwed onto the flame scanner and adjusted for the IR or UV range by
means of a toggle switch. The device has to be adjusted sufficiently for detection of the simu-
lation.
DANGER!
Explosion hazard!
Flame sensors must not be tested in a potentially explosive atmosphere
You will find the technical specifications for this device in section 11.1.4 Flame Scanner Test-
ing Device FFP30.
