17
3 Product Description
Insulation piece for thermical decoupling of FFS07 659S3900
For more information, refer to document "Brackets for Flame Scanner Systems" (DLT7660)
Fig. 3-7 Insulation piece for flame brackets
Fig. 3-8 Temperature according to thermical decoupling
NOTICE
The specifications do not take into account the influence of ambient temperature or radiant
heat on the Flame Scanner.
Cooling air housing FS30 for FFS07 659R0109
Cooling air housing FS65 for FFS08 659R3109
An overview of all brackets and cooling air housing for LAMTEC flame scanner can be found
in the document "Flame Monitoring Systems and Accessories" (DLT7673).
