Network Interface UDS-10B
5-4
Network Interface
The UDS-10B has a 9-30VDC power plug, a reset switch, and an RJ45 (10Base-T)
Ethernet port that supports 10 Mbps.
Figure 5-3: UDS-10B Network Interface
1
8
1 - Tx
+
2 - Tx
-
3 - Rx
+
6 - Rx
-
