NMS045 Reference Manual Wiring Diagram 1-5
Figure 1-3 is color coded to show the options and their components:
• Blue - COM-RV50X-045NA/EU:APAC Cellular Gateway
• Purple - SEN031-045, SEN032-045 Weather/Wind System
• Green - Solar Powered System
• Orange - AC Powered System
• Pink - Batteries, one or two
• Not colored - 831C0-45 base system for the NMS045
FIGURE 1-3 System Wiring Diagram - Options
