Message Explanation
Page #
Calibration point #4 facing up
Horizontal Angle Compass Calibration Routine.
31
Calibration point #5 rotated facing forward
Tilt Sensor Calibration Routine.
23
Calibration point #5 rotated facing forward
Horizontal Angle Compass Calibration Routine.
31
Calibration point #6 rotated facing down
Tilt Sensor Calibration Routine.
23
Calibration point #6 rotated facing down
Horizontal Angle Compass Calibration Routine.
31
Calibration point #7 rotated facing back
Tilt Sensor Calibration Routine.
23
Calibration point #7 rotated facing back
Horizontal Angle Compass Calibration Routine.
31
Calibration point #8 rotated facing up
Tilt Sensor Calibration Routine.
23
Calibration point #8 rotated facing up
Horizontal Angle Compass Calibration Routine.
31
Calibration – Tilt Sensor Calibration Menu 23
Calibration –Horizontal Angle Compass Calibration
Menu
31
Closest target mode.
40
Continuous target mode.
40
Declination value set. AZ only.
35
Declination.
25
Fail reason #1 Tilt Sensor Calibration Routine. 24
Fail reason #1 Horizontal Angle Compass Calibration
Routine.
32
Fail reason #2 Tilt Sensor Calibration Routine. 24
Fail reason #2 Horizontal Angle Compass Calibration
Routine.
32
Fail reason #3 Tilt Sensor Calibration Routine. 24
Fail reason #3 Horizontal Angle Compass Calibration
Routine.
32
Fail reason #4 Tilt Sensor Calibration Routine. 24
Fail reason #4 Horizontal Angle Compass Calibration
Routine.
32
