Laser Technology, Inc. TruPulse L2 User’s Manual 1st Edition
Section 4 - Basic Operations
Page 9
Copyright© 2023, Laser Technology, Inc. All rights reserved.
TruPulse L2 Display
The TruPulse L2 is equipped dual color display and can show information in Red or black. With a built-in light sensor
that reads ambient light. The internal software adjusts the red brightness intensity based on the measured light reading.
Change Display Options:
1. Press the DISP/MENU button to toggle the Automatic brightness display.
2. Short Press the button to change the display color from black to red.
NOTE For low light conditions, it is recommended to use the red display (Figure 7A),
and in bright sunny conditions, the black display (Figure 7B).
Display Indicators:
The TruPulse L2's internal firmware is organized into options. Each option represents a specific measurement or
setup function and has a corresponding display indicator. Refer to Figure 7 and table below for information
about each indicator.
NOTE Within this manual, when the scope ring is represented by a dashed line, the display indicators
have been enlarged to show detail and are used for illustration only.
AB
Figure 7
Display Icons Description Definition
Lower
Main Display
Displays messages and distance measurement results.
Upper Main Display Displays messages and inclination measurement results.
Percent Slope Inclination measurement units.
Degrees
Feet Distance measurement units.
Selection available in the System Setup Mode.
Meters
Battery Status Battery life indicator.
