iCE40 Ultra Breakout Board
Evaluation Board User Guide
© 2014-2020 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02034-1.2 27
Item
Reference
Quantity
Part
PCB Footprint
PART_NUMBER
Manufacturer
Description
15
J3
1
DONE
HDR1X2-40
77311-801-02LF
FCI
CONN HEADER .100 SINGL STR
2POS
16
J4
1
HEADER 3X2
HDR3x2
—
—
—
17
J5
1
PMOD Connector
HDR_6x2_2MM
87758-1216
Molex
CONN HEADER 12POS 2 MM
VERT GOLD
18
J6,J7
2
Header2x10
hdr_samtec_mtsw
_2x10_100
MTSW-110-08-G-D-265
Samtec
CONN HEADER 20POS .100"
TH GLD
19
J8
1
SKT_MINIUSB_B
_RA
skt_miniusb_b_ra
5075BMR-05-SM-CR
Neltron
CONN MINI USB RCPT RA TYPE
B SMD
20
J9
1
TSW-102-07-G-S
hdr_samtec_tsw_1
x2_100
TSW-102-07-G-S
Samtec
CONN HEADER 2POS .100" SGL
GOLD
21
J10
1
TSW-102-07-F-D
hdr_samtec_tsw_2
x2_100
TSW-102-07-F-D
Samtec
CONN HEADER 4POS .100"
DBL
22
J50
1
HDR 1X3 100MIL
HDR_1X3_100MIL
—
—
—
23
J51
1
2 PIN JPR
2PIN_100MIL
—
—
—
24
L1,L2,L3
3
600 OHM 800MA
fb0603
BLM18HE601SN1D
Murata
FERRITE CHIP 600 Ω 800 MA
0603
25
R1,R2,R3,R4,R5,R6,R32
7
0
cr0603
RC0603JR-070RL
Yageo
RES 0.0 OHM 1/10W JUMP
0603 SMD
26
R7,R12
2
2.2K
cr0603
ERJ-3EKF2201V
Panasonic
RES 2.2K OHM 1/10W 1% 0603
SMD
27
R8,R9,R10,R33,R34,R35,R36
7
10K
cr0603
RC0603FR-0710KL
Yageo
RES 10.0K OHM 1/10W 1%
0603 SMD
28
R11
1
12K
cr0603
RC0603FR-0712KL
Yageo
RES 12.0K OHM 1/10W 1%
0603 SMD
29
R14,R38
2
1
cr0603
CRCW06031R00FKEAH P
Vishay
RES 1.00 OHM .25W 1% 0603
SMD
30
R15,R96
2
1
cr0603
RC0603FR-07100RL
Yageo
RES 100 OHM 1/10W 1% 0603
SMD
31
R17
1
10k
R0603
ERJ-3EKF1002V
Panasonic
RES 10K OHM 1/10W 1% 0603
SMD
32
R18
1
2k2
R0603
ERJ-3EKF2201V
Panasonic
RES 2.2K OHM 1/10W 1% 0603
SMD
33
R22,R28
2
0.1
cr0603
ERJ-3RSFR10V
Panasonic
RES .10 OHM 1/10W 1% 0603
SMD
34
R23
1
357K
cr0603
ERJ-3EKF3573V
Panasonic
RES 357K OHM 1/10W 1%
0603 SMD
