iCE40 Ultra Breakout Board
Evaluation Board User Guide
© 2014-2020 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
28 FPGA-EB-02034-1.2
Item
Reference
Quantity
Part
PCB Footprint
PART_NUMBER
Manufacturer
Description
35
R24,R30
2
100
cr0603
RC0603FR-07100RL
Yageo
RES 100 Ω 1/10W 1% 0603
SMD
36
R25,R26
2
1M
cr0603
CRCW06031M00FKEA
Vishay
RES 1.00M Ω 1/10W 1% 0603
SMD
37
R27
1
210K
cr0603
ERJ-3EKF2103V
Panasonic
RES 210K Ω 1/10W 1% 0603
SMD
38
R31
1
1K
cr0603
RC0603FR-071KL
Yageo
RES 1.00K Ω 1/10W 1% 0603
SMD
39
R93,R98
2
2.2K
R0603
ERJ-3EKF2201V
Panasonic
RES 2.2K Ω 1/10W 1% 0603
SMD
40
R94,R97
2
100
SM_R_0603
ERJ-3GEYJ101V
Panasonic
RES 100 Ω 1/10W 5% 0603
SMD
41
R95
1
150
SM_R_0603
ERJ-3GEYJ151V
Panasonic
RES 150 Ω 1/10W 5% 0603
SMD
42
SW1
1
CRST
2psmd_eswitch
TL1015AF160QG
E-Switch
SWITCH TACTILE SPST-NO
0.05A 12 V
43
TP1, TP2, TP3, TP4, TP5,
TP6, TP7, TP8, TP9, TP10,
TP11
11
TP_S_40_63
tp_s_40_63
—
—
Square test point, 40 mil inner
diameter, 63 mil outer
diameter
44
U1
1
FT2232HL
tqfp64_0p5_12p2x
12p2_h1p6
FT2232HL-REEL
FTDI
IC USB HS DUAL UART/FIFO 64-
LQFP
45
U2
1
93LC56-SO8
so8_50_244
93LC56CT-I/SN
Microchip
IC EEPROM 2 KBIT 3 MHZ
8SOIC
46
U5
1
LT3030EFE#TRP
BF
tssop20_26_260_t
hrm_pad
LT3030EFE#TRPBF
Linear
IC REG LDO ADJ 20TSSOP
47
U7
1
N25Q032A13ESC
40F
so8_50_244
N25Q032A13ESC40F
Micron
IC Flash Mem Serial-SPI 3
V/3.3 V 32M-Bit
4M 7 ns 8-Pin SO T/R
48
U8
1
ICE5LP4KSWG36
36_WLCSP
—
—
—
49
U9
1
LED TRI-
COLOUR_1
6-PLCC
SFT722N-S
Seoul Semicon- ductor
Inc
LED RED/GRN/BLU CLEAR
LENS 6PLCC
50
X1
1
12.0000 MHZ
osc_4p_dsc3001
DSC3001HE2-
012.0000T
Mircel
OSCILLATOR 12.0000 MHZ -
20'C to 70'C +/-
25 ppm 1.6 mm x 1.2 mm SMD
51
Thunder Breakout Board
PCB
1
—
—
305-PD-14-0XXX
PACTRON
—
