LAUNCH X-431TOP User’s Manual
5
Connectors and Diagnostic Cables
Fig 1-4 DAEWOO-12 Fig. 1-5 FIAT-3 Fig. 1-6 TOYOTO-16
Fig.1-7 TOYOTO-17 Fig.1-8 TOYOTO-17F Fig.1-9 FORD-6+1
Fig. 1-10 CHRYSLER-6 Fig. 1-11 SUZUKI-3
Fig. 1-12 MAZDA-17 Fig. 1-13 ISUZU-3
Fig. 1-14 KIA-20 Fig. 1-15 OBDⅡ-16C Fig. 1-16 AUDI-4 Fig. 1-17 BMW-16

Launch X-431TOP Specifications

General

Brand	Launch
Model	X-431TOP
Category	Test Equipment
Language	English
