LAUNCH X-431TOP User’s Manual
6
Fig. 1-18 BMW-20 Fig. 1-19 BENZ-38 Fig. 1-20 HONDA-3
Fig. 1-21 DAIHATSU-4 Fig.1-22 NISSAN-14+16
Fig.1-23MITSUBISHI/HYUNDAZ-12+1 Fig.1-24 GMNAZ-12 Fig.1-25 SMART-3
Fig.1-26 CITROEN-2 Fig.1-27 SMART OBDⅡ-16 Fig.1-28 TOYOTO-22
Fig.1-29 BENZ-14 Fig.1-30 SSANGYONG-14
Fig.1-31 SABARU-9 Fig.1-32 CAN connector

Launch X-431TOP Specifications

General

Brand	Launch
Model	X-431TOP
Category	Test Equipment
Language	English
