Launch X-431TOP User Manual

LAUNCH X-431TOP User’s Manual
10
1-10
19
[SUZUKI-3]DIAGNOSTIC
CONNECTOR
1
Diagnose SUZUKI3PIN
diagnostic socket model
See fig.
1-11
20
[ISUZU-3]DIAGNOSTIC
CONNECTOR
1
Diagnose ISUZU3PIN
diagnostic socket model
See fig.
1-13
21
[DAIHATSU -4]DIAGNOSTIC
CONNECTOR
1
Diagnose DAIHATSU4PIN
diagnostic socket model
See fig.
1-21
22
[CITROEN/FUKANG-2]DIAGNOSTIC
CONNECTOR
1
Diagnose CITROEN/FUKANG
2PIN diagnostic socket model
See fig.
1-26
23
[MAZDA-17F]DIAGNOSTIC
CONNECTOR
1
Diagnose HAIMA CA7130
See fig.
1-12
24
[BMW-16]DIAGNOSTIC CONNECTOR
1
Diagnose BMW16PIN
diagnostic socket model
See fig.
1-17
25
[OBDⅡ-16C]DIAGNOSTIC
CONNECTOR
1 Diagnose all the systems except
CAN BUS system of OBDⅡwith
CAN BUS
See fig.
1-27
26
[DAEWOO-12]DIAGNOSTIC
CONNECTOR
1
Diagnose DAEWOO12PIN
diagnostic socket model
See fig.
1-4
27
[TOYOTO-16]DIAGNOSTIC
CONNECTOR
1
Diagnose TOYOTO16PIN
diagnostic socket model
See fig.
1-6
28
[SABARU-9]DIAGNOSTIC
CONNECTOR
1
Diagnose SABARU-9PIN
diagnostic socket model
See fig.
1-31
29
[TOYOTO-22]DIAGNOSTIC
CONNECTOR
1
Diagnose TOYOTO22PIN
diagnostic socket model
See fig.
1-28
30
[COMBI-4]DIAGNOSTIC
CONNECTOR
1
Diagnose COMBI4PIN
diagnostic socket model
Not
available
31
[SEDAN-3]DIAGNOSTIC
CONNECTOR
1
Diagnose SEDAN3PIN
diagnostic socket model
Not
available
32
[BENZ-3]DIAGNOSTIC CONNECTOR
1
Diagnose BENZ3PIN diagnostic
socket model
Not
available
33
[BENZ-14]DIAGNOSTIC
CONNECTOR
1
Diagnose BENZ14PIN
diagnostic socket model
See fig.
1-29
34
[SSANG YONG-14]DIAGNOSTIC
CONNECTOR
1
Diagnose SSANG YONG14PIN
diagnostic socket model.
See fig.
1-30
35
[CAN]DIAGNOSTIC CONNECTOR
1
Diagnose CAN BUS system.
See fig.
1-32
36 [VOLVO CAN]DIAGNOSTIC
CONNECTOR
1 Diagnose VOLVO vehicle with
CANBUS.
See fig.
