Launch X-431TOP User Manual

LAUNCH X-431TOP User’s Manual
11
1-33
37 KES secondary signal cable 1 Acquire secondary signal
See fig.
1-39
38 Secondary signal induction cable 1 Acquire variety of secondary
signal of vehicle without
high tension cable
See fig.
1-37
39
KES-200 一 cylinder signal clamp
1 Acquire cylinder signal
Not
available
40
20MM crocodile clip（red）
4
See fig.
1-45
41 Electricity control patch cord 1 5 Convenient to input signal for
test.
See fig.
1-40
42 Electricity control patch cord 2 5 Convenient to input signal for
test.
See fig.
1-41
43 Electricity control patch cord 3 5 Convenient to input signal for
test.
See fig.
1-42
44 Electricity control patch cord 4 5 Convenient to input signal for
test.
See fig.
1-43
45 Oscilloscope cable 4 Signal acquisition
See fig.
1-36
46 Oscilloscope probe 4 Signal acquisition
See fig.
1-44
47 Oscilloscope GND cable 1
See fig.
1-38
48 Sensor diagnostic cable 1 Diagnose sensor
See fig.
1-35
49 Diagnostic cable 1 Connect DIAGNOSTIC
CONNECTOR and X-431TOP
Terminal
See fig.
1-34
50 Cigar lighter power supply 1 Acquire power supply from
vehicle cigar lighter
See fig.
1-46
51 Battery cable w/two clips 1 Acquire power supply from
vehicle battery
Not
available
52 Primary signal patch cord 4
Transfer signal when check
primary signal and electricity
control sensor. Used to
connect the signal for primary
signal test and electrical
control sensor test.
Convenient to input signal for
test.
See fig.
1-47
