LCI SlimRack - Slide Room Installation into the RV Body

Rev: 03.19.21 Page 16 CCD-0004319
Slide Room Installation
1. Measure the slide room width and the wall opening (Fig. 19). The wall opening needs to be 5 3/4"
wider than the actual slide room measurement. Do not attempt to install the slide room in the trailer if
this dimension is more than 6" or less than 5 1/2".
Fig. 19
Wall Opening Width =
Slide Room Width + 5
¾
" (+/ -
¼
")
Slide Room Width
(Measurement does
not include fascia)
