Rev: 03.19.21 Page 3 CCD-0004319
1. To optimize slide-out operation, park trailer on solid and level ground. Parking locations should be
clear of obstructions that may cause damage when the slide-out room is actuated.
2. Make sure all persons are clear of the trailer prior to the slide-out room actuation.
3. Keep hands and other body parts away from slide-out mechanisms during actuation.
General Requirements
• Power and wiring MUST be such that there is not less than 10.5 running volts supplied at the motor leads
under maximum load.
• Slide system controllers MUST come from Lippert Components. Controllers supplied by other companies
will void warranty.
• Voltage supply MUST come from a 12V DC automotive/RV type battery.
Always make sure that the slide-out room path is clear of people and objects before and during
operation of the slide-out. Always keep away from the gear racks when the room is being operated.
Do not work on your slide-out system unless the battery is disconnected. Failure to act in
accordance with the following may result in death or serious personal injury.
The In-Wall® Slide-out System is intended for the sole purpose of extending and retracting the slide-
out room. It should not be used for any purpose other than to actuate the slide-out room. To use
the system for any reason other than what it is designed for may result in death, serious injury or
damage to the trailer.
Moving parts can pinch, crush or cut. Keep clear and use caution.
Introduction
NOTE: This manual outlines the installation and service for the slide-out systems utilizing auto-
programmable controllers, paired with rocker switch. This document supersedes Power Gear
documents 3010002588 (for controller Power Gear 1510000199 / LCI 366697) Rev 0E and
3010002813 (for controller Power Gear 1510000236 / LCI 366701) Rev 0G both dated December
2014.
The Lippert Components, Inc. (LCI) SlimRack Slide-Out System is a rack-and-pinion design operated by a
12V DC gear motor. Changes to weight, stroke, weight distribution, rail position, controller, power supply
seals, slide toppers, ramps, rollers, etc. all have an effect on the performance of the system. In order to
secure warranty coverage, each new application or changes to existing applications MUST be audited and
approved by Lippert Components with a signed document. Audits can be arranged by contacting your
account representative.
For information on the assembly or individual components of this product, please visit:
https://support.lci1.com/slide-outs-support-slimrack.
NOTE: Images used in this document are for reference only when assembling, installing and/or operating
this product. Actual appearance of provided and/or purchased parts and assemblies may differ.
Safety
