Controller Fault Codes
Fault Code
Flashes
Fault Type Description Why? What Should Be Done?
Green Red
1 1 Minor
Park Brake Not
Set
• Park Brake Not Set, if
applicable.
• Ground signal lost at
park brake receptacle at
controller.
• Set parking brake (if
applicable).
• Check for continuity to ground
on wire plugged into park
brake receptacle at controller.
1 2 Minor Low Voltage
Incoming voltage to controller is
below 12V DC. The slide-out will
NOT move if voltage is 10.5V DC or
below.
Start vehicle, generator, or make sure
unit is plugged into shore power.
Check 2-pin power connector at
controller at BATT + and GND −.
Consult manufacturer of unit's charging
system for troubleshooting assistance.
1 4 Major Motor 1 Fault
Bad wire connection
Refer to 82-S0533 for troubleshooting.
This Technical Information Sheet can be
obtained on-line at: https://www.lci1.com/
slide-outs-/support-slimrack then click on the
Technical Information Sheets tab and and
look for document 82-S0533, Troubleshooting
Control Box for SlimRack® Systems.
Bad motor
2 4 Major Motor 2 Fault
Bad wire connection
Bad motor
1 6 Minor High Voltage
Supply voltage to controller is 17V
DC or greater.
Consult manufacturer of unit's charging
system for troubleshooting assistance.
1 7 Major
Stops Not
Programmed
• Stops have not been set
• Stops were cleared
• Stops were improperly
set
Stops need to be programmed
according to the programing
instructions in this document.
1 8 Major
Fuse,
Motor 1
Fuse for Motor 1 concern. Contact Lippert representative.
2 8 Major
Fuse,
Motor 2
Fuse for Motor 2 concern. Contact Lippert representative.
1 9 Minor
Battery
Drop Out
Battery dropped below 8.5V while
extending or retracting slide.
Charge battery, start vehicle, generator,
or make sure unit is pugged into shore
power.
To Next Page
