17. External Interface
17-5
Command Parameters
CINELITE:DISPLAY:MEAS_SIZE 1X1, 3X3, 9X9, or ?
CINELITE:FSTOP:REF_MODE —
CINELITE:FSTOP:REF_SET —
CINELITE:DISPLAY:%/RGB LEVEL%, RGB%, RGB255, or ?
CINELITE:GAMMA 0.45, USER-1, USER-2, USER-3 /
USER-A, USER-B, USER-C, USER-D, USER-E,
or ?
CINELITE:CAL:TABLE_CLEAR —
CINELITE:CAL:DATA_CLEAR —
CINELITE:CAL:SET —
CINELITE:CAL:CAL_F 22.0, 16.0, 11.0, 8.0, 5.6, 4.0, 2.8, 2.0, or ?
CINELITE:CAL2:TBL_CLR —
CINEZONE —
CINEZONE:SEARCH —
CINEZONE:SEARCH:LEVEL –7.3 to 109.4, or ?
CINEZONE:DSIPLAY LINEAR, STEP, or ?
CINEZONE:UPPER –6.3 to 109.4, or ?
CINEZONE:LOWER –7.3 to 108.4, or ?
WFM —
WFM:INTEN:WFM –128 to 127, or ?
WFM:INTEN:SCALE –8 to 7, or ?
WFM:GAIN:VAR CAL, VAR, or ?
WFM:GAIN:MAG 1, 5, or ?
WFM:GAIN:FILTER FLAT, LOW_PASS, or ?
WFM:GAIN:C.FILTER FLAT, FLAT+LUM, or ?
WFM:SWEEP:SWEEP H, V, or ?
WFM:SWEEP:H_SWEEP 1H, 2H, or ?
WFM:SWEEP:V_SWEEP 1V, 2V, or ?
WFM:SWEEP:FIELD 1, 2, or ?
WFM:SWEEP:H_MAG 1, 10, 20, ACTIVE, BLANK, or ?
WFM:SWEEP:V_MAG 1, 20, 40, or ?
WFM:LINE_SEL:LINE_SELECT ON, OFF, or ?
WFM:LINE_SEL:LINE_NUMBER 1 to 1125, or ?
WFM:LINE_SEL:FIELD 1, 2, FRAME, or ?
WFM:COLOR:MATRIX YCBCR, GBR, RGB, COMPOSIT, or ?
WFM:COLOR:YGBR ON, OFF, or ?
WFM:COLOR:YRGB ON, OFF, or ?
WFM:COLOR:SETUP 0, 7.5, or ?
WFM:SCALE:UNIT V%, V, %, or ?
WFM:SCALE:COLOR75P ON, OFF, or ?
WFM:EAV_SAV REMOVE, PASS, or ?
WFM:TIMING NORMAL, PASS, or ?
WFM:MODE OVERLAY, PARADE, TIMING, or ?
WFM:DISPLAY:CH1 ON, OFF, or ?
WFM:DISPLAY:CH2 ON, OFF, or ?
WFM:DISPLAY:CH3 ON, OFF, or ?
VECTOR —
VECTOR:INTEN:VECTOR –128 to 127, or ?
